Denso Aircon Compressor DCP32022

Compressor, Air Conditioner

• Clutch Type: DL / B-PC
• Compressor Type: 7SEU17C
• DNTS short code: 447190-9080
• Filled: Filled
• Gross Weight (g): 5920
• Height Incl Packaging (mm): 290
• Indication Reman Part: New
• Length Incl Packaging (mm): 320
• Mounting Type: Bolted
• Net Weight (g): 5110
• Number of grooves: 6
• Number of ribs: 6
• OE Manufacturer: VW-Group
• OE Number: 7L6820803T
• Oil Quantity: 140
• Oil Type: ND-Oil 8
• Oil Type 2: ND-8
• Pulley Diameter(mm): 110
• Pulley type: DL-Pulley
• Quality: DENSO
• Refrigerant Type: R134a
• Width Incl Packaging (mm): 220

Replaces OEM reference(s):
AUDI: 7L6820803C, AUDI: 7L6820803F, AUDI: 7L6820803J, AUDI: 7L6820803K, AUDI: 7L6820803M, AUDI: 7L6820803Q, AUDI: 7L6820803T, AUDI: 7P0820803D, AUDI: 7P0820803N, Denso: 43710054403D, Denso: 44719090803D, PORSCHE: 95512601112, PORSCHE: 955 126 011 12, VOLKSWAGEN: 7L6820803C, VOLKSWAGEN: 7L6820803F, VOLKSWAGEN: 7L6820803J, VOLKSWAGEN: 7L6820803K, VOLKSWAGEN: 7L6820803M, VOLKSWAGEN: 7L6820803Q, VOLKSWAGEN: 7L6820803T, VOLKSWAGEN: 7P0820803D, VOLKSWAGEN: 7P0820803N

Replaces aftermarket reference(s):
BEHR HELLA SERVICE: 8FK 351 322-311, BEHR HELLA SERVICE: 8FK 351 322-811, BEHR HELLA SERVICE: 8FK351322311, BEHR HELLA SERVICE: 8FK351322811, DENSO: 2483001010, DENSO: 2483002060, DENSO: 4371005440, DENSO: 4471502410, DENSO: 4471808590, DENSO: 4471907580, DENSO: 4471909080, DENSO: 4472600110, DENSO: 4472601620, DENSO: 4472602020, DENSO: 4472604260, DENSO: 248300-1010, DENSO: 248300-2060, DENSO: 437100-5440, DENSO: 447150-2410, DENSO: 447180-8590, DENSO: 447190-7580, DENSO: 447190-9080, DENSO: 447260-0110, DENSO: 447260-1620, DENSO: 447260-2020, DENSO: 447260-4260, ELSTOCK: 510395, ELSTOCK: 51-0395, FRIGAIR: 92030168, FRIGAIR: 93030168, MAHLE: 72440547, MAHLE: ACP 110, MAHLE: ACP 110 000P, MAHLE: ACP 110 000S, MAHLE: ACP110, MAHLE: ACP110000P, MAHLE: ACP110000S, NISSENS: 89091, NRF: 32611, NRF: 32611G, WAECO: 8880100428
