Description
Compressor, Air Conditioner
- Compressor Type: 6SES14C
- Filled: Filled
- Gross Weight (g): 5200
- Height Incl Packaging (mm): 290
- Indication Reman Part: New
- Length Incl Packaging (mm): 320
- Mounting Type: Bolted
- Net Weight (g): 4390
- Number of grooves: 6
- Number of ribs: 6
- OE Manufacturer: VW-Group
- OE Number: 5Q0816803D
- Oil Quantity: 110
- Oil Type: ND-Oil 12
- Oil Type 2: ND-12
- Pulley Diameter(mm): 110
- Pulley type: DL-Pulley
- Quality: DENSO
- Refrigerant Type: R134a; R1234yf
- Width Incl Packaging (mm): 220
Replaces OEM reference(s):
VAG: 5Q0816803, VAG: 5Q0816803B, VAG: 5Q0816803D, VAG: 5Q0816803E, VAG: 5Q0816803F
Replaces aftermarket reference(s):
DENSO: 4471507746, ELSTOCK: 511000, ELSTOCK: 51-1000
