HC Cargo Aircon Compressor 241034

Voltage: 12
Family type: 6SEU14C
Mount. holes/front 2: 9.00
Dist. between holes 1: 70.00
Dist. between holes 2: 70.00
Dist. between mount. bracket/hole: 145.00
Dist. between mount. bracket/hole 2: 145.00
Position: 10
Position 2: 5
Length mm: 230.00
Inlet: 28.40
Outlet: 15.30
Pulley Dist. B1: 48.00
Pulley Dist. B2: 30.00
Pulley Grooves: 6
Pulley type: SP
Pulley OD mm: 110.00
Oil type: PAG 46
Oil capacity: 140 ml.
Refrigerant: R134a
O-ring: w/o
Remarks: IMPORTANT! Oil Filling. 1. Drain the oil from the compressor and measure the amount of oil. 2. Fill with the additional oil quantity and oil type as required from the vehicle manufacturer. Please be careful not to combine the different kinds of oil types.

Replaces OEM reference(s):
BMW 6987862, BMW 64526987862, Denso 4471908460, Denso 447260-1850, Denso 447260-1851, Denso 447260-1852

Replaces aftermarket reference(s):
Ava (Quality Cooling) BWK387, FrigAir 92030223, Hella 8FK351334-971, NRF 32533
