HC Cargo Aircon Compressor 241122

Voltage: 12
Family type: HS18
Mount. holes/front 2: 9.00
Dist. between holes 1: 83.00
Dist. between holes 2: 95.00
Dist. between mount. bracket/hole: 68.00
Dist. between mount. bracket/hole 2: 56.00
Position: 55
Position 2: 5
Length mm: 223.00
Inlet: 18.80
Outlet: 13.00
Pulley Dist. B1: 89.00
Pulley Dist. B2: 67.50
Pulley Grooves: 7
Pulley type: DP
Pulley OD mm: 120.00
Oil type: PAG 46
Oil capacity: 180 ml.
Refrigerant: R134a
Remarks: IMPORTANT! Oil Filling. 1. Drain the oil from the compressor and measure the amount of oil. 2. Fill with the additional oil quantity and oil type as required from the vehicle manufacturer. Please be careful not to combine the different kinds of oil types.

Replaces OEM reference(s):
Kia 97701-4a900, Kia 97701-4a970

Replaces aftermarket reference(s):
Ava (Quality Cooling) HYK257, Elstock 51-0732, lucas ACP831, NRF 32716, NRF 32716G
