HC Cargo Aircon Compressor 241534

Voltage: 12
Family type: PXE14
Mount. holes/front 2: 9.00
Dist. between holes 1: 70.00
Dist. between holes 2: 70.00
Dist. between holes 3: 70.00
Dist. between mount. bracket/hole: 141.00
Dist. between mount. bracket/hole 2: 141.00
Dist. between mount. bracket/hole 3: 138.00
Position: 45
Position 2: 60
Length mm: 238.00
Inlet: 28.40
Outlet: 15.30
Pulley Dist. B1: 59.50
Pulley Dist. B2: 42.00
Pulley Grooves: 6
Pulley type: SP
Pulley OD mm: 110.00
Oil type: PAG 46-H
Oil capacity: 100 ml.
Refrigerant: R134a/R1234yf
O-ring: w/
Remarks: IMPORTANT! Oil Filling. 1. Drain the oil from the compressor and measure the amount of oil. 2. Fill with the additional oil quantity and oil type as required from the vehicle manufacturer. Please be careful not to combine the different kinds of oil types.

Replaces OEM reference(s):
Volkswagen 5Q0816803F, Volkswagen 5Q0816803K, Volkswagen 5Q0820803E
