Description
Voltage: 12
Family type: 5SEL12C
Mount. holes/front 2: 10.50
Dist. between holes 1: 80.00
Dist. between holes 2: 80.00
Dist. between holes 3: 80.00
Dist. between mount. bracket/hole 2: 92.00
Dist. between mount. bracket/hole 3: 128.00
Position: 55
Position 2: 48
Length mm: 215.00
Rotation: CW
Inlet: 20.70
Outlet: 14.40
Pulley Dist. B1: 56.50
Pulley Dist. B2: 39.00
Pulley type: SP
Pulley OD mm: 119.00
Pulley: w/
Oil type: PAG 46-H
Oil capacity: 110 ml.
Refrigerant: R1234yf
Remarks: IMPORTANT! Oil Filling. 1. Drain the oil from the compressor and measure the amount of oil. 2. Fill with the additional oil quantity and oil type as required from the vehicle manufacturer. Please be careful not to combine the different kinds of oil types.
Replaces OEM reference(s):
Peugeot 9675657880, Peugeot 9675659980, Peugeot 9802456780, Peugeot 9809274880, Valeo C813179H, Valeo Z0015961B, Valeo Z0015961D, Valeo Z00159-61G
Replaces aftermarket reference(s):
Denso DCP21017, Mahle Letrika ACP503000P, NRF 320103G, Valeo 813179
