HC-Cargo Alternator for Austin-Healey 70A F032110497

Voltage: 14
Amp: 70
Terminal: W
Pulley dist.: 42.50
Width/holder arm: 10.50
Mount. bracket dist.: 84.00
Bracket hole: 10.00
Belt. adj. brackethole pos.: 55
Belt. adj. brackethole pos. 3: 5
Belt. adj. brackethole pos. 2: 60
Belt. adj. bracket hole: 8.00
Pulley dia.: 73.00
Grooves/pulley: 1
Radius: 83.50
Radius 2: 82.50
Radius 3: 82.50
Radius 4: 82.50
B+: 9.40
Position/B+ in min.: 20
D+ Size: 6.30
Rotation: CW
Plug no.: PL22
W plug type: M5
Total length mm: 166.00
Pulley: P
Regulator type: IR
Prod. info: BN
Servicing: Austin-Healey

Replaces OEM reference(s):
Bosch 9120690170, HC-PARTS ca1457ir, lucas 66021070, lucas 66021155, lucas 66921126, lucas nab900

Replaces aftermarket reference(s):
AD Kühner 301457RI, AD Kühner 301550RI, Autostarter Poland A4036, Bosch Blue F042306030, Bowers - HCUK BAO3211, Casco CAL11108, Elstock 28-8626, ERA S.p.A Italia 209248, ERA S.p.A Italia 209248A, Hella 8el737662-001, Pos Service Holland 015.002.065, Prestolite - HCUK 66021126, Prestolite - HCUK 66021126K, Spidan 5764, Unipoint ALT-4036, Unipoint Bosch F042A06030, Wai 12750N, Wood Auto ALT16000, Wood Auto ALT4036
