Description
Voltage: 14
Amp: 60
Pulley dist.: 43.00
Width/holder arm: 21.00
Bracket hole: 10.20
Belt. adj. brackethole pos.: 60
Belt. adj. bracket hole: M8
Pulley dia.: 69.00
Grooves/pulley: 1
Radius: 77.50
Radius 2: 75.00
B+: M6
Position/B+ in min.: 45
Rotation: CW
Plug no.: PL10
Total length mm: 150.00
Pulley: P
Regulator type: IR
Replaces OEM reference(s):
Denso 101211-8520, Denso 101211-8521, Denso 101211-8522, Kubota 3A611-74012
Replaces aftermarket reference(s):
Ac delco DRA0316, Casco CAL40177, Dansk Renoveringsindustri 583.112.602, Denso DAN2038, Elstock 28-6624, lucas LRA03514, Pos Service Holland 695.512.060, Pos Service Holland 995.507.060, Wai 11903N
