Description
Voltage: 28
Amp: 75
Terminal: W
Width/holder arm: 13.40
Mount. bracket dist.: 83.20
Bracket hole: 8.20
Belt. adj. brackethole pos.: 50
Belt. adj. bracket hole: M8
Radius: 86.00
Radius 2: 86.00
B+: M6
Position/B+ in min.: 10
D+ Size: M5
Rotation: CW
Plug no.: PL31
W plug type: 6.30
Total length mm: 184.50
Regulator type: IR
Prod. info: BN
Replaces OEM reference(s):
Caterpillar 3469827, Caterpillar 4246821, Caterpillar 225-3146, Caterpillar 225-3147, Caterpillar 346-9826, Denso 102211-8150, Denso 102211-8151, Hyster 1556256, Jcb 714-40208, Magneti Marelli 63377466, Perkins 3991485, Perkins 2871A702, Perkins 2871A705, Perkins T416234, Perkins T416349
Replaces aftermarket reference(s):
Ac delco DRA0032, AD Kühner 553276RI, Autostarter Poland A4128S, Casco CAL30604, Denso DAN652, Elstock 48-5810, lucas LRA03198, Magneti Marelli 063377466010, Wai 12814N, Wood Auto DENDAN652
