HC-Cargo Starter Motor for Case International 3.1 kw F032111885

Oil and waterproof.

Voltage: 12
kW: 3.1
No./teeth: 9
Rotation: CW
Gear type: DD
Mount. flange: 89.00
B+: M10
No./mount. holes: 3 (0)
Drive dist.: 48.00
Mount. hole 1 mm: 11.00
Mount. hole 2 mm: 11.00
Mount. hole 3 mm: 11.00
Dist./back: 235.00
Dist./front: 95.50
Terminal 50: M4
Position/50: 45
Dist. mm: 90.00
Dist. 2: 127.00
Dist. 3: 90.00
Total length mm: 332.50
Drive type: Steel
Prod. info: BN
Waterproof: Yes
Oil sealed: Yes
Remarks: Oil and waterproof.

Replaces OEM reference(s):
AGCO C000900060210, Bosch 0001367019, Bosch 0001367072, Bosch 0001369007, Bosch 0001369019, Bosch 0001369025, Case 114799A1, Case 114800A1, Case A187597, Cummins 3283312, Cummins 3283812, HC-PARTS cs1069, Mahle Letrika 11.130.664, Mahle Letrika 11.130.695, Mahle Letrika azj3216, Mahle Letrika AZJ3236

Replaces aftermarket reference(s):
Ac delco DRS0295, Ac delco DRS3947, AD Kühner 101069, Autostarter Poland S0631S, Bosch 0986025443, Casco CST10339, Dansk Renoveringsindustri 600.073.092, Dansk Renoveringsindustri 685.017.092, Dansk Renoveringsindustri 685.032.092, Elstock 25-2040, Elstock 25-4261, Hella 8ea737443-001, Lester 17307, lucas LRS01300, lucas LRS02589, Mahle Letrika is0664, Mahle Letrika IS0695, Mahle Letrika MS271, PIC 120-566, PIC 120-599, PIC 120-599A, Prestolite - HCUK 20513045, Prestolite - HCUK PBNS3045, Spidan 4534, Wai 17307N, Wood Auto STR22106
