HC-Cargo Starter Motor for Caterpillar 7.5 kw F032110347

Replacing: 50MT.

Voltage: 24
kW: 7.5
No./teeth: 11
Rotation: CW
Gear type: DD
Mount. flange: 92.00
Insulated return: Yes
B+: 1/2" UNC
No./mount. holes: 3 (0)
Drive dist.: 47.00
Mount. hole 1 mm: 16.50
Mount. hole 2 mm: 16.50
Mount. hole 3 mm: 16.50
Dist./back: 374.00
Dist./front: 101.50
B-: 1/2" UNC
Terminal 50: M8/10.00
Position/50: 2
Dist. mm: 127.00
Dist. 2: 127.00
Dist. 3: 127.00
Total length mm: 522.00
Drive type: Steel
Prod. info: BN
Oil sealed: Yes
Info: .
Remarks: Replacing: 50MT.

Replaces OEM reference(s):
Bosch 0001420002, Bosch 0001420006, Bosch 0001420008, Bosch 0001420010, Bosch 0001420011, Butec MS7-410C, Case 462588C91, Caterpillar 2371962, Caterpillar 2727123, Caterpillar 3383454, Caterpillar 0R4259, Caterpillar 0R4272, Caterpillar 0r5213, Caterpillar 10R9815, Caterpillar 10R9816, Caterpillar 272-7123, Caterpillar 2T0797, Caterpillar 338-3454, Caterpillar 3l8205, Caterpillar 3t2780, Caterpillar 3T2782, Caterpillar 3t2785, Caterpillar 3t2787, Caterpillar 3t3778, Caterpillar 3t8947, Caterpillar 3t8949, Caterpillar 3t8954, Caterpillar 3t8967, Caterpillar 4n0959, Caterpillar 4n3343, Caterpillar 4n3349, Caterpillar 5l3648, Caterpillar 5l4405, Caterpillar 5l5353, Caterpillar 5l648, Caterpillar 5lg48, Caterpillar 6N1886, Caterpillar 6n9667, Caterpillar 6n9677, Caterpillar 6t0640, Caterpillar 6t0647, Caterpillar 6V0511, Caterpillar 6V0513, Caterpillar 6V0885, Caterpillar 6v0890, Caterpillar 8l8205, Caterpillar 9l6464, Caterpillar 9l6484, CAV 2311040, Cummins 173184, Cummins 3000576, Cummins 3010125, Cummins 3021038, Cummins 3632274, Cummins 3636820, Cummins 3636821, Cummins 3651892, Cummins 4081235, Cummins 4081236, Cummins 3010125rx, Cummins 3603868rx, Cummins 3603888rx, DAF 1516993R, Fiat 4780974, HC-PARTS us827, Iveco 4780974, Remy (delco) 1109222, Remy (delco) 1109285, Remy (delco) 1109286, Remy (delco) 1109287, Remy (delco) 1109288, Remy (delco) 1109289, Remy (delco) 1109290, Remy (delco) 1109291, Remy (delco) 1109292, Remy (delco) 1109293, Remy (delco) 1109296, Remy (delco) 1109385, Remy (delco) 1109494, Remy (delco) 1109553, Remy (delco) 1109631, Remy (delco) 1109636, Remy (delco) 1109638, Remy (delco) 1109642, Remy (delco) 1109643, Remy (delco) 1109647, Remy (delco) 1109649, Remy (delco) 1109661, Remy (delco) 1109755, Remy (delco) 1109759, Remy (delco) 1109768, Remy (delco) 1109771, Remy (delco) 1109772, Remy (delco) 1109773, Remy (delco) 1109774, Remy (delco) 1109775, Remy (delco) 1109776, Remy (delco) 1109777, Remy (delco) 1109778, Remy (delco) 1109780, Remy (delco) 1109782, Remy (delco) 1109787, Remy (delco) 1109788, Remy (delco) 1109789, Remy (delco) 1109791, Remy (delco) 1109798, Remy (delco) 1109833, Remy (delco) 1109834, Remy (delco) 1109836, Remy (delco) 1109838, Remy (delco) 1109839, Remy (delco) 1109840, Remy (delco) 1109841, Remy (delco) 1109842, Remy (delco) 1109845, Remy (delco) 1109846, Remy (delco) 1109960, Remy (delco) 1109961, Remy (delco) 1109965, Remy (delco) 1109971, Remy (delco) 1109972, Remy (delco) 1109973, Remy (delco) 1109977, Remy (delco) 1109978, Remy (delco) 1109979, Remy (delco) 1109986, Remy (delco) 1109987, Remy (delco) 1114819, Remy (delco) 1990229, Remy (delco) 1990231, Remy (delco) 1990235, Remy (delco) 1990237, Remy (delco) 1990239, Remy (delco) 1990248, Remy (delco) 1990249, Remy (delco) 1990250, Remy (delco) 1990251, Remy (delco) 1990259, Remy (delco) 1990260, Remy (delco) 1990262, Remy (delco) 1990264, Remy (delco) 1990266, Remy (delco) 1990268, Remy (delco) 1990269, Remy (delco) 1990270, Remy (delco) 1990271, Remy (delco) 1990272, Remy (delco) 1990273, Remy (delco) 1990274, Remy (delco) 1990276, Remy (delco) 1990284, Remy (delco) 1993840, Remy (delco) 10461057, Remy (delco) 10461125, Remy (delco) 10478809, Remy (delco) 10478855, Remy (delco) 10478879, Remy (delco) 10478880, Remy (delco) 10478884, Remy (delco) 10478911, Remy (delco) 10478912, Remy (delco) 10479339, Remy (delco) 10479340, Renault 5000811448, Unic 004780974

Replaces aftermarket reference(s):
Ac delco DRS0314, Ac delco drz5104, Ac delco drz5111, Ac delco drz5115, Ac delco drz5119, Ac delco drz5144, Ac delco DRZ5189, Ace CM-4051, Ace CM-5091, AD Kühner 60827, Autostarter Poland S1009, Autostarter Poland S1202S, Birkson BK10.N79339, Bosch 0986015680, Bosch Blue F042003048, Bosch Blue F042003073, Bosch USA SR954X, Bowers - HCUK BSO7189, Casco CST60605, Dansk Renoveringsindustri 600.068.114, Elstock 45-0440, Elstock 45-2059, Elstock 45-5204, FARCOM 103527, Friesen 88-15.680, GAUSS INDUSTRIA GA21057, GAUSS INDUSTRIA GA21367, Hella 8ea730307-001, Lester 18022, Lester 18038, Lester 3295, Lester 3902, Lester 4600, Lester 4927, Lester 6245, Lester 6672, Lester 6764, lucas LRS01829, lucas LRS01946, lucas LRS04041, Magneti Marelli 943251568, PIC 120-803, PIC 120-803A, PIC 120-821, PIC 140-9849, PIC 142-182, PIC 142-186, PIC 142-187, PIC 142-188, PIC 142-188A, PIC 142-194, PIC 142-197, PIC 142-253, PIC 902-940, PIC 902-976, PIC 902-977, PIC 910-284, PIC 940-360, Spidan 1647, Sud Est 33555, Sud Est 33617, Sud Est 33849, Unipoint STR-4200, Unipoint STR-4302, Unipoint Bosch F042S03048, Unipoint Bosch F042S03073, Valeo 201015, Valeo 438516, Wai 3745N, Wai 3902N, Wai 3902R, Wai 4930N, Wai 50-111, Wai 50-111-1, Wai 50-111-2, Wood Auto STR20012, Wood Auto STR21011
