Description
Replacing: PG260L.
Voltage: 12
kW: 1.6
No./teeth: 11
Rotation: CW
Gear type: GR
B+: M8
No./mount. holes: 2 (0)
Drive dist.: 18.00
Mount. hole 1 mm: 10.20
Mount. hole 2 mm: 10.20
Dist./back: 171.00
Dist./front: 57.00
Terminal 15a: M5
Position/15a: 45
Thread length mm: 12.00
Terminal 50: M5
Position/50: 15
Dist. mm: 83.00
Total length mm: 243.00
Drive type: Steel
Prod. info: BN
Remarks: Replacing: PG260L.
Replaces OEM reference(s):
Arco Marine 30470, Remy (delco) 9000885
Replaces aftermarket reference(s):
Aep sdr0031, Autostarter Poland S1008, Bosch USA sr8538x, Dixie s-1437, Hyster 1469604, PIC 140-6068, Rcp 21973A, Rcp 21976a, Rcp st-6560, Rcp st-6562, ROMAINE 30450, Wai 2-2323-DR, Wai 2-2323-DR-2, Wai 6407N, Wai 6407R, Wai 6562NM, Wai 6562R
