HC-Cargo Starter Motor for Cummins 2.5 kw F032115352

Voltage: 12
kW: 2.5
No./teeth: 10
Rotation: CW
Gear type: GR
Mount. flange: 89.00
B+: M10
No./mount. holes: 2 (0)
Drive dist.: 48.00
Mount. hole 1 mm: 11.00
Mount. hole 2 mm: 11.00
Dist./back: 161.00
Dist./front: 73.00
B-: M10
Position/b-: 50
Terminal 50: M5
Position/50: 40
Dist. mm: 127.00
Total length mm: 294.50
Clutch type: Dry
Prod. info: BN

Replaces OEM reference(s):
Cummins 3971610, Cummins 3971613, Cummins 3971614, Cummins 3971615, Denso 428000-2900, Denso 428000-2910, Denso 428000-2911, Denso 428000-2920, Denso 428080-2910, Denso 428080-2920, Hyster 1654059

Replaces aftermarket reference(s):
AD Kühner 254396, Autostarter Poland S6374S, Casco CST40332, Denso DSN2049, Denso DSN2050, Elstock 25-5177, FARCOM 106696, Lester 19806, lucas LRS04015, Pos Service Holland 640.518.102, Wai 19104N
