HC-Cargo Starter Motor for Iveco 3.0 kw F032114002

Voltage: 12
kW: 4.2
No./teeth: 10
Rotation: CW
Gear type: GR
Mount. flange: 89.00
B+: M10
No./mount. holes: 3 (0)
Drive dist.: 27.00
Mount. hole 1 mm: 10.50
Mount. hole 2 mm: 10.50
Mount. hole 3 mm: 10.50
Dist./back: 228.00
Dist./front: 76.00
Terminal 50: M4-6.30
Position/50: 15
Dist. mm: 90.00
Dist. 2: 127.00
Dist. 3: 90.00
Total length mm: 316.00
Drive type: Steel
Prod. info: BN

Replaces OEM reference(s):
Agritalia (Carraro) 394677, Bosch 0001230021, Bosch 0001230026, Bosch 0001250003, Bosch 0001250004, Bosch 0001262021, Bosch 0001262022, Case 2859528, Case 47137538, Case 51635200, Case 87337538, Claas 0011383370, Claas 11383370, Fiat 47132888, Fiat 47137534, Fiat 5802430573, Iveco 285217, Iveco 8094570, Iveco 50435711, Iveco 50436476, Iveco 0000504031929, Iveco 0000504036476, Iveco 504036476, Iveco 0000504357109, Iveco 0000504357110, Iveco 504357110, Iveco 0005801577137, Iveco 5801577138, Iveco 5802094025, Iveco 5802430573, Komatsu EA504357109, Mahle Letrika 11.131.352, Mahle Letrika 11.132.260, Mahle Letrika AZF4591, New Holland 51635200, New Holland 84208903

Replaces aftermarket reference(s):
Ac delco DRS0026, Ac delco DRS0267, AD Kühner 255227, Autostarter Poland S0256, Autostarter Poland S0786S, Autostarter Poland S0810S, Autostarter Poland S9232, Casco CST10268, Casco CST10538, Mahle Letrika IS1109, Mahle Letrika MS168, Mahle Letrika MS677, Pos Service Holland 500.572.103, Wai 19792N, Wai 19861N, Wai 19980N
