HC-Cargo Starter Motor for JCB 4.0 kw F032115776

Voltage: 24
kW: 4.0
No./teeth: 11
Rotation: CW
Gear type: GR
Mount. flange: 89.00
Position/B+: 60
B+: M10
No./mount. holes: 3 (0)
Drive dist.: 20.00
Mount. hole 1 mm: 11.20
Mount. hole 2 mm: 11.20
Mount. hole 3 mm: 11.20
Dist./back: 250.00
Dist./front: 68.50
B-: M8
Position/b-: 28
Thread length mm: 24.00
Terminal 50: M4-6.30
Position/50: 45
Dist. mm: 90.00
Dist. 2: 90.00
Dist. 3: 127.00
Total length mm: 352.00

Replaces OEM reference(s):
Jcb 320/A9080, Jcb 320-09023, Jcb 320-09033, Jcb 320-09347, Jcb 320-09453, Jcb 320-A9080, Jcb 320-A9453, Mahle Letrika 11.131.303, Mahle Letrika 11.131.805, Mahle Letrika 11.131.849, Mahle Letrika 11.131.995, Mahle Letrika 11.132.230, Mahle Letrika AZF4211, Mahle Letrika AZF4225, Mahle Letrika AZF4267, Mahle Letrika AZF4579

Replaces aftermarket reference(s):
Autostarter Poland S9097, Autostarter Poland S9097(LETRIKA), Casco CST21617, Mahle Letrika IS1106, Mahle Letrika MS5, Pos Service Holland 701.512.113, Wai 33415N
