HC-Cargo Starter Motor for Kubota 1.0 kw F032110447

Voltage: 12
kW: 1.0
No./teeth: 9
Rotation: CW
Gear type: GR
Mount. flange: 66.00
Position/B+: 15
B+: M8
No./mount. holes: 2 (0)
Drive dist.: 17.00
Mount. hole 1 mm: 9.00
Mount. hole 2 mm: 9.00
Dist./back: 126.00
Dist./front: 30.00
Terminal 50: 6.30
Position/50: 10
Dist. mm: 109.50
Total length mm: 200.00
Clutch type: Dry
Drive type: Steel
Prod. info: BN

Replaces OEM reference(s):
Case 1959380C1, Denso 028000-8320, Denso 028000-8321, Denso 028000-8322, Denso 128000-3590, Denso 128000-3591, Denso 128000-5261, Denso 128000-9950, Denso 128000-9951, Denso 128000-9958, Denso 228000-0790, Denso 228000-0791, Denso 228000-0800, Denso 228000-0970, Denso 228000-0971, Denso 228000-0980, Denso 228000-0981, Denso 228000-7150, Denso 228000-7151, Denso 428000-2640, HC-PARTS js730, Kubota 1627163013, Kubota 15471-63011, Kubota 15504-63010, Kubota 15504-63011, Kubota 15504-63012, Kubota 15741-63010, Kubota 15741-63011, Kubota 16285-63010, Kubota 16612-63011, Kubota 16612-63012, Kubota 16695-63011, Kubota 16695-63012, Kubota 16695-63013, Kubota 16871-63010, Kubota 16871-63011, Kubota 16871-63012, Kubota 19400-63011, Kubota 19420-63012, Kubota 37560-63010, Kubota 37560-63011, Kubota 37560-63012, Kubota k3511-81410, Kubota K7571-96800, Kubota K7571-96810

Replaces aftermarket reference(s):
Ac delco drs3229, Ac delco DRS3966, AD Kühner 20730, Autostarter Poland S6045, Bosch 0986023460, Bosch Blue F042000195, Bosch Blue F042001127, Casco CST40143, Dansk Renoveringsindustri 683.010.092, Dansk Renoveringsindustri 683.031.092, Denso DSN2079, Elstock 25-1164, Elstock 25-2194, Elstock 25-3157, Elstock 25-5267, Hella 8ea730270-001, Hella Timefit 8EA012527-111, Lester 17028, Lester 18414, lucas LES0281, lucas LRS01169, PIC 190-316, PIC 190-316A, PIC 190-316B, PIC 190-432, PIC 190-6023, PIC 911-228, Pos Service Holland 690.509.092, Pos Service Holland 690.546.092, Spidan 4253, Unipoint STR-3569, Unipoint STR-8110, Unipoint Bosch F042S00195, Unipoint Bosch F042S01127, Wai 17028N, Wai 17098N, Wai 18400N, Wai 18400R, Wai 18414N, Wai 18417N, Wai 18419N, Wai 2-2036-ND, Wood Auto STR30012
