HC-Cargo Starter Motor for Perkins 2.7 kw F032111346

Voltage: 12
kW: 2.8
No./teeth: 10
Rotation: CW
Gear type: DD
Mount. flange: 89.00
B+: M8
No./mount. holes: 3 (0)
Drive dist.: 29.50
Mount. hole 1 mm: 11.00
Mount. hole 2 mm: 11.00
Mount. hole 3 mm: 11.00
Dist./back: 217.00
Dist./front: 77.00
Terminal 50: 6.30
Position/50: 15
Dist. mm: 126.50
Dist. 2: 89.50
Dist. 3: 89.50
Total length mm: 308.00
Clutch type: Dry
Drive type: Steel
Prod. info: BN

Replaces OEM reference(s):
Bosch 9004475061, HC-PARTS cs994, Jcb 714-14300, Jcb 714-29500, Jcb 714-40005, lucas 26414, lucas 27541, lucas 27547, lucas 27565, lucas 27568, lucas 27589, lucas 27590, lucas 27598, lucas 27602, lucas 27608, lucas 27610, lucas 27620, lucas 27626, lucas 27627, lucas 27629, lucas 26298d, lucas 26414a, lucas 26414e, lucas 26925196a, lucas 27541a, lucas 27541d, lucas 27565b, lucas 27565d, lucas 27568a, lucas 27627B, Magneti Marelli 63227479, Magneti Marelli 63227541, Magneti Marelli 63227565, Magneti Marelli 63227568, Magneti Marelli 63227590, Magneti Marelli 63227598, Magneti Marelli 63227599, Manitou 745309, Massey Ferguson 3763362M94, Perkins 2873006, Perkins 1873a054, Perkins 1873a055, Perkins 26414r, Perkins 2873A029, Perkins 2873A031, Perkins 2873b072, Perkins 2873b073

Replaces aftermarket reference(s):
Ac delco drs3287, Ac delco DRS3769, AD Kühner 10994, Autostarter Poland S4019, Bosch 0986022680, Bowers - HCUK BSO7018, Casco CST25132, Dansk Renoveringsindustri 644.002.102, Dansk Renoveringsindustri 685.028.102, Elstock 25-0041, Elstock 25-1030, Elstock 25-2402, FARCOM 104087, FARCOM 104306, Hella 8ea737243-001, Hella Timefit 8EA012527-161, Lester 17652, lucas LES0041, lucas lrs00969, Mahle Letrika is0629, PIC 180-306, PIC 180-306A, PIC 180-308C, Prestolite - HCUK 20500969, Spidan 4451, Sud Est 33473, Wai 16670N, Wai 17652N, Wai 18482N, Wood Auto STR25000
