HC-Cargo Starter Motor for Perkins 3.0 kw F032116307

Iskra version.

Voltage: 12
kW: 3.2
No./teeth: 10
Rotation: CW
Gear type: DD/GR
Mount. flange: 89.00
B+: M8
No./mount. holes: 3 (0)
Drive dist.: 29.00
Mount. hole 1 mm: 10.80
Mount. hole 2 mm: 10.80
Mount. hole 3 mm: 10.80
Dist./back: 200.00
Dist./front: 76.00
B-: M8
Position/b-: 10
Thread length mm: 15.00
Terminal 50: M6
Position/50: 15
Dist. mm: 90.00
Dist. 2: 127.00
Dist. 3: 90.00
Total length mm: 299.00
Prod. info: BN
Remarks: Iskra version.

Replaces OEM reference(s):
AGCO 3823621M92, AGCO 3823621M93, AGCO 3823621M94, AGCO 3823621M96, AGCO 6306848M91, ARGO 3667040M91, ARGO 3680133M91, Butec 860714, Case 388186A2, Caterpillar 3575202, Caterpillar 5269854, Caterpillar 225-3148, Claas 11445780, Jcb V, Landini 3667040M91, Landini 3680133M91, Mahle Letrika 11.131.228, Mahle Letrika 11.131.410, Mahle Letrika 11.131.606, Mahle Letrika 11.131.780, Mahle Letrika 11.131.946, Mahle Letrika 11.131.964, Mahle Letrika 11.132.035, Mahle Letrika 11.132.149, Mahle Letrika AZE4272, Manitou 958578, Massey Ferguson 1447773R1, Massey Ferguson 3784889M2, Massey Ferguson 3784890M1, Massey Ferguson 3823621M91, Massey Ferguson 3823621M95, MCCORMICK 388186A1, MCCORMICK 388186A2, MCCORMICK 388186A3, Perkins 3586847, Perkins 2873k621, Perkins 2873k632, Perkins T400268, Perkins t410874

Replaces aftermarket reference(s):
Ac delco DRS0066, Ac delco DRS0279, Autostarter Poland S9144, Autostarter Poland S9172(LETRIKA), Autostarter Poland S9417S, Casco CST21106, Casco CST21107, Casco CST21186, Casco CST30161, Elstock 25-3377, Elstock 25-4271, ERA S.p.A Italia 220814, ERA S.p.A Italia 220814A, FARCOM 107091, lucas LRS02598, Mahle Letrika IS1195, Mahle Letrika MS111, Mahle Letrika MS289, Pos Service Holland 650.505.103, Wai 18941N, Wai 18941R, Wai 30529N, Wai 33410N
