HC-Cargo Starter Motor for Perkins 3.0 kw F032116308

Iskra version.

Voltage: 12
kW: 3.2
No./teeth: 10
Rotation: CW
Gear type: GR
Mount. flange: 89.00
Position/B+: 60
B+: M8
No./mount. holes: 3 (0)
Drive dist.: 29.50
Mount. hole 1 mm: 11.00
Mount. hole 2 mm: 11.00
Mount. hole 3 mm: 11.00
Dist./back: 200.00
Dist./front: 76.00
B-: M8
Position/b-: 10
Thread length mm: 15.00
Terminal 50: M6
Position/50: 20
Dist. mm: 127.00
Dist. 2: 90.00
Dist. 3: 90.00
Total length mm: 296.50
Prod. info: BN
Remarks: Iskra version.

Replaces OEM reference(s):
AGCO 26194600, AGCO 29194800, Caterpillar 3575203, Caterpillar 225-3149, Caterpillar 312-7540, Caterpillar 329-0290, Caterpillar 365-3422, HATTAT 9HM12008A6A, Jcb 714-40159, Jcb 714-40231, Magneti Marelli 63227479, Mahle Letrika 11.131.077, Mahle Letrika 11.131.605, Mahle Letrika 11.131.761, Mahle Letrika 11.131.781, Mahle Letrika 11.131.793, Mahle Letrika 11.131.942, Mahle Letrika 11.131.947, Mahle Letrika 11.131.989, Mahle Letrika 11.132.036, Mahle Letrika AZE4150, Mahle Letrika AZE4170, Mahle Letrika AZE4173, Mahle Letrika AZE4175, Mahle Letrika AZE4197, Mahle Letrika AZE4201, Mahle Letrika AZE4220, Mahle Letrika AZF4545, Manitou 605002, Manitou 958579, Massey Ferguson 3542185M93, Massey Ferguson 3821818M91, Perkins 2873K624, Perkins 2873K625, Perkins 2873K626, Perkins 2873K634, Perkins 3873k625, Perkins 3873K627, Perkins T410865, Perkins T412689

Replaces aftermarket reference(s):
Ac delco DRS3954, Ac delco DRS3954N, AD Kühner 254358, Autostarter Poland S9087, Autostarter Poland S9098, Autostarter Poland S9098(LETRIKA), Autostarter Poland S9364S, Casco CST21108, Casco CST21187, Elstock 25-4149, ERA S.p.A Italia 220702, ERA S.p.A Italia 220702A, lucas les0393, lucas LRS02477, Mahle Letrika IS1201, Mahle Letrika MS399, Wai 18940N-IK, Wai 18940R, Wai ISK-1201
