HC-Cargo Starter Motor for Smart 0.8 kw F032115951

Voltage: 12
kW: 0.8
No./teeth: 9
Rotation: CW
Gear type: DD
Mount. flange: 70.00
B+: M8
No./mount. holes: 2 (2)
Drive dist.: 15.00
Mount. hole 1 mm: M8
Mount. hole 2 mm: M8
Dist./back: 124.00
Dist./front: 47.00
Terminal 50: 6.30
Position/50: 15
Dist. mm: 100.00
Total length mm: 172.00

Replaces OEM reference(s):
Bosch 1986S01022, HC-PARTS cs1206, Magneti Marelli 63101007, Magneti Marelli 63191007, Mercedes Benz 0051510701, Mercedes Benz 0051512601, Mercedes Benz 0003188V006, Mercedes Benz A0003188V006, Mercedes Benz A0051510701, Mercedes Benz A0051512601, Smart 0003188V004, Smart 0003188V005, Smart 0003188V006, Smart 0003188V007, Smart 0003188V008, Smart Q0003188V004000000, Smart Q0003188V005000000, Smart Q0003188V006000000, Smart Q0003188V007000000

Replaces aftermarket reference(s):
Ac delco DRS3878, Ac delco DRS3878X, AD Kühner 101206, Autostarter Poland S4051, Autostarter Poland S6109(DENSO), Bosch 0986022151, Casco CST30115, Denso DSN583, Elstock 25-2395, FARCOM 104776, Friesen 8080046, Hella Timefit 8EA011611-471, lucas LRS01461, Magneti Marelli 063191007, Magneti Marelli 063191007010, Magneti Marelli 944280800460, Magneti Marelli MSN800, Pos Service Holland 550.902.092, Unipoint Bosch F042S0H042, Valeo 458471, Wai 32461N, Wai 32461R, Wood Auto DENDSN583
