HC-Cargo Starter Motor for Volvo Penta 3.1 kw F032111047

Voltage: 12
kW: 3.1
No./teeth: 9
11
Rotation: CW
Gear type: GR
Mount. flange: 89.00
Insulated return: Yes
B+: M8
No./mount. holes: 3 (0)
Drive dist.: 48.00
Mount. hole 1 mm: 10.30
Mount. hole 2 mm: 10.30
Mount. hole 3 mm: 10.30
Dist./back: 197.00
Dist./front: 91.00
B-: M8
Position/b-: 37
Terminal 50: M5
Position/50: 15
Dist. mm: 127.00
Dist. 2: 90.00
Dist. 3: 90.00
Total length mm: 303.50
Drive type: Steel
Prod. info: BN

Replaces OEM reference(s):
Bosch 0001359119, Bosch 0001367049, DAF 1516806R, HC-PARTS cs1035, Renault 7701499545, Valeo D11E167, Valeo d11e167t, Valeo d9r116, Valeo d9r144, Volvo 859252, Volvo 1359119, Volvo 1367049, Volvo 1542195, Volvo 1545417, Volvo 3581774, Volvo 3803200, Volvo 5001759, Volvo 22175633

Replaces aftermarket reference(s):
Ac delco DRS0904, Ac delco DRS2780, Ac delco DRS3744, AD Kühner 101035, AD Kühner 10783, Autostarter Poland S3042, Bosch 0986012780, Bosch 0986012781, Bosch 0986012783, Bosch 0986017131, Casco CST15155, Cevam 8697, Dansk Renoveringsindustri 638.001.092, Dansk Renoveringsindustri 638.016.112, Dansk Renoveringsindustri 638.046.092, Elstock 25-0462, Elstock 25-1420, ERA S.p.A Italia 220792, ERA S.p.A Italia 220792A, FARCOM 106479, Friesen 88-12.780, Hella 8ea737252-001, Lester 16464, Lester 17316, lucas LES0237, lucas LRS01100, lucas LRS01250, Magneti Marelli 943252233, Magneti Marelli 943252233010, Mahle Letrika MS263, Mahle Letrika MS41, PIC 108-246, Pos Service Holland 810.020.113, Pos Service Holland 810.021.093, Spidan 4460, Sud Est 33629, Sud Est 33630, Valeo 184202, Valeo 203003, Valeo 455537, Valeo 484202, Valeo nd147, Wai 17316N, Wai 2-2248-PR, Wai 31141R, Wood Auto STR54022
