Description
Voltage: 12
kW: 1.1
No./teeth: 9
Rotation: CW
Gear type: GR
Mount. flange: 89.00
B+: M8
No./mount. holes: 2 (0)
Drive dist.: 17.00
Mount. hole 1 mm: 12.00
Mount. hole 2 mm: 11.00
Dist./back: 153.00
Dist./front: 53.50
Terminal 50: 6.30
Position/50: 45
Dist. mm: 127.00
Total length mm: 209.00
Replaces OEM reference(s):
Denso 228000-7470, Denso 228000-7471, Denso 228000-7472, John Deere AM809215, John Deere AM879204, John Deere se501858, John Deere TY25238, Yanmar 119626-77010, Yanmar 119626-77011
Replaces aftermarket reference(s):
AD Kühner 254009, Autostarter Poland S6337(DENSO), Casco CST20181, Casco CST20185, Casco CST40507, Dansk Renoveringsindustri 682.045.092, Denso DSN2078, Elstock 25-4421, Lester 18426, Pos Service Holland 980.542.092, Wai 18426N
