HC-Cargo Starter Motor for Yanmar 1.1 kw F032114891

Voltage: 12
kW: 1.1
No./teeth: 9
Rotation: CW
Gear type: GR
Mount. flange: 80.00
B+: M8
No./mount. holes: 2 (0)
Drive dist.: 21.00
Mount. hole 1 mm: 11.00
Mount. hole 2 mm: 11.00
Dist./back: 149.00
Dist./front: 54.00
Terminal 50: 6.30
Position/50: 45
Dist. mm: 120.00
Total length mm: 202.00
Prod. info: BN

Replaces OEM reference(s):
Denso 428000-1590, Denso 428000-1591, Denso 428000-2190, Denso 428000-2191, Denso 428000-2192, John Deere MIU800612, Yanmar 119515-77010, Yanmar 119717-77010

Replaces aftermarket reference(s):
AD Kühner 254524, Autostarter Poland S6183, Casco CST40330, Cevam 8233, Dansk Renoveringsindustri 682.043.092, Dansk Renoveringsindustri 682.047.092, Denso DSN2137, Elstock 25-4381, Elstock 25-4443, FARCOM 106421, Lester 19615, Lester 19897, lucas LRS02709, Pos Service Holland 980.526.092, Wai 19615n
