HC-Cargo Starter Motor for Yanmar 2.3 kw F032112676

Voltage: 12
kW: 2.2
No./teeth: 9
Rotation: CW
Gear type: GR
Mount. flange: 95.00
B+: M8
No./mount. holes: 2 (0)
Drive dist.: 20.50
Mount. hole 1 mm: 13.50
Mount. hole 2 mm: 13.50
Dist./back: 210.00
Dist./front: 21.00
Terminal 50: M4-6.30
Position/50: 20
Dist. mm: 119.50
Total length mm: 231.00
Clutch type: Wet
Drive type: Steel
Prod. info: BN

Replaces OEM reference(s):
Agritalia (Carraro) 40121132, Hitachi s13-204, Hitachi S13-404, Hyster 1599845, John Deere AT211995, Yanmar 129900-77010, Yanmar 129900-77011, Yanmar 129900-77040, Yanmar 4TNE98

Replaces aftermarket reference(s):
AD Kühner 254136, Autostarter Poland S2041, Birkson BK10.N13204, Bosch Blue F042004030, Bosch Blue F042200200, Casco CST20144, Casco CST21178, Casco CST32157, Cevam 8919, Elstock 25-3064, Lester 18491, lucas LRS01565, Mahle Letrika MS449, Pos Service Holland 980.510.092, Unipoint STR-6016, Unipoint Bosch F042S04030, Valeo 600051, Wai 18491N, Wood Auto STR6016
