HELLA Asymmetric-Headlight - 24/12V 1AA004109-031

Asymmetric-Headlight - 24/12V - Reference number: 10 - ECE - transparent - Plug: Blade Terminal - right/left

HELLA front lighting. Look ahead - with front lighting solutions from HELLA. Nothing works without powerful headlights - neither on the road nor in the field. They are the eyes of the vehicle and therefore an essential safety feature when driving and working at night.

• Main headlamp for installation - for right-hand traffic, with ECE approval
• The headlamp has 3 light functions: Low beam / High beam / Position light
• Lamp type: R2 (Bilux)/T4W, without bulbs
• Width: 173mm - Height: 144mm - Depth: 99mm - Lamp Type: T4W/R2 (Bilux) - without bulbs
• Light functions: 3 - with low beam/with high beam/with position light
• Registration Type: ECE - for right-hand traffic - Prot.type (IP Code): IP5K4K
• Housing Colour: Black - Diffusing Lens Material: Glass - Lens Colour: transparent

Item Attributes:
Mounting Type: Fitting
Fastening Type: Vertical
Lamp Type: R2 (Bilux) / T4W
Light Design: Asymmetric
Voltage: 24 V / 12 V
Fitting Position: right / left
Width: 173 mm
Height: 144 mm
Depth: 99 mm
Light Function: with low beam / with high beam / with position light
Light functions: 3
Prot.type (IP Code): IP5K4K
Registration Type: ECE
Plug: Blade Terminal
Reference number: 10
Left-hand/Right-hand Traffic: for right-hand traffic
Housing Colour: black
Illuminated Area: 138 x 124 mm
Diffusing Lens Material: Glass
Lens Colour: transparent
Supplementary Article/Supplementary Info 2: without bulbs
Assembly by qualified personnel required!

OE references: ATLAS COPCO 1360074; BOMAG H-41 493 31; CASE IH 1570425; CASE IH 9 803274 4; CATERPILLAR 157-0425; DAF 867443; DELVANO 51101570425; GOLDHOFER 111201600; HAKO 90-22568-1; HAMM 00311987; KAMAG 80308342; KÖGEL 308342; KOMATSU 20G0 6K1 130; KOMATSU 20G-06-H0P01; KOMATSU 20G-06-K1130; KOMATSU 20G-06-K2480; KOMATSU 2OG0 6K1 130; KOMATSU 4901 612 M1; LIEBHERR 6 000 830; MAFI 000,580,0019; O&K 1570425; TEREX 1360074; TEREX 3600136074; VOLVO 20005174004; VOLVO 5174004; YANMAR 3600136074
