HELLA Control Unit, lights - 12V 5DS011630-001

Control Unit, lights - 12V - ECE - LED

Application: To check LED dipped beam headlamps or LED beacons, the average energy requirement is determined by means of a current measurement. The current monitors are matched to HELLA products and enable very reliable control. Structure and function: The control unit is connected upstream of the LED headlamp and continuously measures the current consumption when switched on. If a minimum current value is exceeded, the correct function of the spotlight is indicated by a high level at the status output, if it is fallen short of, the defect of the spotlight is indicated by a low level. Monitoring only takes place when the ignition is switched on and the light function is switched on.

• For individual function monitoring of LED headlights and beacons
• Failure indication via status output; for vehicles with 12 V on-board voltage
• Connector pattern compatible with ISO 7588-2
• Registration Type: ECE

Item Attributes:
Lamp Type: LED
Light Design: LED
Registration Type: ECE
Voltage: 12 V
Charging Rate: 500 mA
Assembly by qualified personnel required!

OE references: CLAAS R01010169; HYMER 2325256; HYMER 8043362; KNAUS R01010169; KNAUS R03030392
