HELLA Control Unit, lights - 24V - 5-pin connector 5DS009602-001

Control Unit, lights - 24V - 5-pin connector - ECE - LED - with LED control unit for indicator

Use only with HELLA LED indicators. If the existing vehicle electrical system is programmed to monitor the lighting even when it is not in operation, this is referred to as a cold check. During a cold check, a small test pulse is transmitted to the lamp while it is switched off to see whether this pulse is discharged via the bulb to ground. The energy here is so low that the bulb does not light up. As LED lamps are essentially not suitable for this form of monitoring, HELLA offers an electronic system for "simulation of the cold check" in order to ensure operation. The simulation device is connected between the central control unit and an ISO 13207-compliant LED direction indicator. The cold check control unit checks the function of the direction indicator during operation using the ISO pulse. If the direction indicator fails, the device saves the last status, which means this can then be displayed during the next cold check.

• Registration Type: ECE
• For individual function monitoring of LED direction indicators compatible with ISO standard 13207-1
• Storage and transmission of the last function status of the LED direction indicator to the central control unit
• For vehicles with 12 V and 24 V vehicle electrical system voltage
• Connector configuration compatible with ISO 7588-2

Item Attributes:
Supplementary Article/Supplementary Info: with LED control unit for indicator
Light Design: LED
Lamp Type: LED
Registration Type: ECE
Voltage: 24 V
Number of pins: 5 -pin connector
for Art.No.: 2VD/2VP 012 381-...
Assembly by qualified personnel required!

OE references: EVOBUS 000 827 00 10; EVOBUS A0008270010; IVECO 5801461374; MERCEDES-BENZ 001 581 00 09; MERCEDES-BENZ A 001 581 00 09; NOGE GG00541003; NOGE GG00541003-A; SCANIA 2197751; SOLARIS 55038
