HELLA DE/Halogen-Headlight - 90mm Performance - 12V 1AL009998-021

DE/Halogen-Headlight - 90mm Performance - 12V - round - Reference number: 12.5 - SAE/ECE - Plug: AMP - right/left

HELLA front lighting. Look ahead - with front lighting solutions from HELLA. Nothing works without powerful headlights - neither on the road nor in the field. They are the vehicle's eyes, so to speak, and thus an essential safety feature when driving and working at night. HELLA's 90 mm front lighting modules are particularly tailored to the needs of trucks and agricultural vehicles and are used in almost all vehicles and situations due to their functional diversity. The modules are small, but powerful - and offer a high degree of flexibility thanks to the modular concept, which allows numerous possible applications, especially in the truck and agricultural sectors. Thanks to the future-proof HELLA upgrade concept, even the classic halogen modules can later be converted to the efficient, bright LED technology that already characterises the majority of the modules.

• Individual front design thanks to modular construction
• Numerous application possibilities even in more demanding environments
• Excellent light output and extremely homogeneous illumination with little scattered light from a 70 mm optic-free lens
• Simple installation with pre-mounted adjusting screws
• Height: 108mm - Depth: 182mm - Lamp Type: H9 - Electromagnetic Compatibility (EMC)
• Light functions: 2 - with high beam/with low beam
• Registration Type: SAE/ECE - for right-hand traffic

Item Attributes:
Mounting Type: Fitting
Lamp Type: H9
Light Design: DE / Halogen
Voltage: 12 V
Fitting Position: right / left
Height: 108 mm
Depth: 182 mm
Light Function: with low beam / with high beam
Light functions: 2
Registration Type: SAE / ECE
Plug: AMP
Reference number: 12.5
Left-hand/Right-hand Traffic: for right-hand traffic
Shape: round
Illuminated Area: 90 mm
Diffusing Lens Material: Glass
Supplementary Article/Supplementary Info 2: Electromagnetic Compatibility (EMC)
SVHC: 7439-92-1; Lead
Assembly by qualified personnel required!

OE references: ALEXANDER DENNIS 76102164; BLUECAR T0920-06575; CASE IH 47573274; FAUN 9970-7035703; FIAT 50526136; FORD USA FS00030978; GILLIG A4859600; LANDINI 6612916A1; MASERATI A00505261540; POLARIS 2412965; VERSATILE 86066075
