HELLA LED-Strobe-type Beacon - RotaLED Compact - 12/24V - yellow (amber) 2XD013979-021

LED-Strobe-type Beacon - RotaLED Compact - 12/24V - yellow (amber) - Magnet Mount - Cable: 200mm - Quantity: 1

The RotaLED Compact beacon is available as a flashing or rotating version. The signal is generated by means of an electronic concept and thus without moving parts. The beacon can be connected to an operating voltage of 10 - 30 V and has an impact-resistant polycarbonate light cover. The height is approx. 118 mm (F) to 164 mm (FL), depending on the design. The RotaLED Compact beacon meets the requirements of IP 67 and IP X9K and is therefore dust-tight and resistant to high-pressure cleaners. Even short-term immersion up to 1 metre under water is possible. The product is attached to the vehicle by means of screws in the case of fixed mounting or by means of a flexible pipe socket or magnetic adapter in the case of the other variants. The beacon is particularly suitable as an attention-grabbing warning signal and for safeguarding danger spots. The RotaLED Compact is the successor to the halogen beacon series Rotafix, Rotaflex and Rota Compact and makes a 1:1 exchange to LED technology possible.

• The RotaLED Compact is the LED successor to the existing halogen beacon series Rotafix, Rotaflex and Rota Compact. These are 1:1 interchangeable
• No moving parts are required for the LED functions - no wear and tear and maximum reliability
• As LEDs are maintenance-free, they do not cause additional spare parts and maintenance costs
• Service life is reduced to a minimum
• The flashing light function ensures good warning effectiveness
• Lamp Type: LED - Number of LEDs: 16 - Power consumption: 10W
• With flashing warning signal - Lens Colour: yellow (amber)

Item Attributes:
Mounting Type: Magnet Mount
Light Design: LED
Lamp Type: LED
Voltage: 12 V / 24 V
Height: 118 mm
Outer Diameter 1: 165 mm
Light Function: With flashing warning signal
Light colour: yellow (amber)
Number of LEDs: 16
Connection type inlet: Cigarette Lighter
Prot.type (IP Code): IP6K7 / IP6K9K
Registration Type: SAE / ADR/GGVS
fulfils ECE standard: R10 / R65
Lens Colour: yellow (amber)
Housing Colour: black
Flash rate per minute: 122
Power consumption: 10 W
Housing material: ABS (Acrylonitrile-Butadiene-Styrene Copolymerisate)
Temperature range from: -40 °C
Temperature range to: +60 °C
Weight: 420 g
Cable: 200 mm
Diffusing Lens Material: PC (Polycarbonate)
Reverse polarity protection: Yes
Permissible Max. Speed: 120 km/h
Quantity: 1
Supplementary Article/Supplementary Info 2: Electromagnetic Compatibility (EMC)
Assembly by qualified personnel required!

OE references: AMMANN 1828056; DAF 1551351; FARESIN ME11080D61; HYUNDAI 21WD-01401; SENNEBOGEN 230503; VOLVO 15240242; VOLVO VOE15240242
