HELLA LED-Worklight - SL60 - 12/24/36/48/60/72V 1G0996210-011

LED-Worklight - SL60 - 12/24/36/48/60/72V - Bolted - Bracket system - Spot Illumination - Cable: 500mm - Plug: open cable ends

The innovative SL60 LED warning light from HELLA is equipped with VISIOTECH projection technology. A special lens optic focuses the light rays of the LED so strongly that a strip-shaped warning line is projected onto the ground. Depending on the mounting, the warning line can be projected horizontally or vertically in front of the vehicle. The application is used to warn other vehicles or passers-by of an approaching vehicle. However, the projected lines in front of the vehicle can also be used for easier vehicle navigation. Occupational safety and comfort are significantly increased in both cases and accidents can thus be prevented in advance. Indoors, for example in the forklift area, the SL60 LED can even be used optimally during the day to make everyday work much easier. Due to its compact dimensions, the SL60 LED warning light is particularly suitable for mounting situations with little space. In addition to its compact dimensions, the SL60 LED also scores with its high energy efficiency. With a maximum power consumption of 7 watts, this warning light is ideal for use on vehicles with battery operation as well as on vehicles whose alternator is already heavily loaded. The multi-voltage electronics allow an operating voltage of 10 to 80 volts. Among other things, this enables use on 48 V forklifts and similar vehicles with a high on-board voltage. The SL60 LED is available in both red and blue projection line versions, making it suitable for a wide range of applications and target groups.

• VISIOTECH projection technology for more safety at work
• Compact warning light projects a striped warning line onto the floor
• Other vehicles or pedestrians can be warned visually
• Suitable for a wide range of applications
• Lamp Type: LED - Number of LEDs: 3 - Power consumption: 5.5W
• Clear diffusing lens
• fulfils ECE standard: R10 - Prot.type (IP Code): IP6K7/IP6K9K

Item Attributes:
Mounting Type: Bolted
Fastening Type: Bracket system
Light Design: LED
Lamp Type: LED
Voltage: 72 V / 48 V / 60 V / 12 V / 36 V / 24 V
Height: 99 mm
Width: 70 mm
Depth: 55 mm
Light Distribution: Spot Illumination
fulfils ECE standard: R10
Plug: open cable ends
Prot.type (IP Code): IP6K7 / IP6K9K
Number of LEDs: 3
Power consumption: 5.5 W
Cable: 500 mm
Housing Colour: black/red
Diffusing Lens Material: Glass
Diffusing Lens Type: Clear diffusing lens
Housing material: Die-Cast Aluminium
Weight: 290 g
Assembly by qualified personnel required!

OE references: DOOSAN 301005-02171; ROSENBAUER 01537B
