HELLA Main Switch, battery - Rotary Operation - Number of connectors: 2 6EK002843-051

Main Switch, battery - Rotary Operation - Number of connectors: 2 - Bolted - Normally Open Contact - Thread Pitch: 1.5mm - with nuts

At HELLA we offer you a wide range of different switches for every function. Whether rotary switches, indicator switches, alarm switches, glow and starter switches, ignition starter switches, multi-function switches, isolators, dimmer foot switches or pushbutton and plunger switches - we have an extensive range for everything that needs to be switched on or off in vehicles. Our counters have one thing in common: The high quality! HELLA's battery disconnectors provide effective safety against theft and fire hazards in the event of accidents in the agricultural and construction machinery industry, for example. Simply pressing the key forcibly closes the vehicle's circuit between the battery, starter and other consumers. Opening (separation) is effected by a return spring. An indispensable safety factor.

• Battery switch with red switch key and silver-plated screw contacts - for battery and ignition current
• Optionally plus or minus line can be switched off, key can be removed in "Off" position
• 2 screw connections, contains 2 screw nuts per bolt
• The continuous load capacity is max. 50A at max. 80° C ambient temperature and a 35 mm cable connected with ring tongues.
• Replacement key: 9SL 706 729-031
• Capacity at 24V: max1000 A/10 sek/24V
• Prot.type (IP Code): IPX4 - DIN/ISO: 40050

Item Attributes:
Mounting Type: Bolted
Connecting thread: M10
Number of connectors: 2
Capacity at 24V: max1000 A/10 sek/24V
Actuation Type: Rotary Operation
DIN/ISO: 40050
Prot.type (IP Code): IPX4
Thread Pitch: 1.5 mm
Switch Function: Normally Open Contact
Rated Current: 150 A
SVHC: 7439-92-1; Lead / 117-81-7; Bis (2-ethylhexyl)phthalate (DEHP)
Supplementary Article/Supplementary Info: with nuts
Assembly by qualified personnel required!

OE references: SANY 60148849
