HELLA Relay, main current - 12V - 5-pin connector - L1 - C3 4RC933364-027

Relay, main current - 12V - 5-pin connector - Wiring Diagramme: L1 - Plug: C3 - Normally Open Contact - without holder

HELLA's quality relays are versatile and always reliable - that's what our many years of original equipment experience and our high level of manufacturing expertise stand for. We produce more than 100 million relays per year in our own production. Renowned car manufacturers have been relying on HELLA's proven quality for decades. The areas of application are varied and include engine control units, headlight cleaning systems, starters, fuel pumps, fan motors, horns and fanfares. HELLA is also certified in various relevant areas, such as DIN EN ISO 9001:2008, ISO / TS 6949:2009, ISO 14001. HELLA relays also comply with the standards of ROHS (2002 / 95 / EC) and REACh. They are available in 12 V and 24 V.

• Micro relay - normally open relay 12 V, 5-pole, bistable, without holder
• Rated switching current: max. 20 A (at 80 °C ambient temperature)
• Number of switching operations: min. 100,000
• Temperature range from: -40°C - Temperature range to: +85°C
• Ohmic Load: 20A - Inductive Load: 20A - Capacitive Load: 20A - Capacity at 12V: 30A

Item Attributes:
Supplementary Article/Supplementary Info: without holder
Voltage: 12 V
Capacity at 12V: 30A
Switch Function: Normally Open Contact
Number of pins: 5 -pin connector
Temperature range from: -40 °C
Temperature range to: +85 °C
Inductive Load: 20 A
Capacitive Load: 20 A
Ohmic Load: 20 A
Wiring Diagramme: L1
Switch: Bistable
Plug: C3
Relay function: Starter / Fan, engine cooling / Daytime Running Light / Central Locking / Exterior Mirror Adjustment / Windscreen Wiper Rest Heating / Interior Blower / Fuel Pump / Convertible Roof Hydraulics / ABS / Fan, heater/air conditioning / Heated rear window / ESP / Windscreen Wiper / Heatable exterior mirror / Window Regulator / Light switch / Electric booster heater / Clamp 15R / Clamp 15 / Secondary Air System / ABS recovery pump / Oxygen Sensor / Comfort Equipment Variant (trim package) / Air Conditioning / Sunroof / Interior Lighting / High Beam / Low Beam / Park Distance Control / Klaxon / Front Fog Light / Clamp 87 / Seat Heating
Assembly by qualified personnel required!

OE references: MERCEDES-BENZ 002 542 81 19; MERCEDES-BENZ A 002 542 81 19; SAME 2.7659.280.0; SCANIA 3054730
