HELLA Relay, main current - 24V - 5-pin connector 4RD933332-201

Relay, main current - 24V - 5-pin connector - Normally Open Contact/Normally Closed Contact/Changeover Contact - with holder

HELLA's quality relays are versatile and always reliable - that's what our many years of original equipment experience and our high level of manufacturing expertise stand for. We produce more than 100 million relays per year in our own production. Renowned car manufacturers have been relying on HELLA's proven quality for decades. The areas of application are varied and include engine control units, headlight cleaning systems, starters, fuel pumps, fan motors, horns and fanfares. HELLA is also certified in various relevant areas, such as DIN EN ISO 9001:2008, ISO / TS 6949:2009, ISO 14001. HELLA relays also comply with the standards of ROHS (2002 / 95 / EC) and REACh. They are available in 12 V and 24 V.

• Mini relay - change-over relay 24 V, 5-pole, with holder and parallel resistor to coil
• Rated switching current: min. 5 A, max. 20 A (at 80 °C ambient temperature)
• Number of switching operations: min. 100,000
• Ohmic Load: 10/20A - Inductive Load: 16/8A

Item Attributes:
Supplementary Article/Supplementary Info: with holder
Voltage: 24 V
Connector/Clamp: W
Inductive Load: 8 A / 16 A
Ohmic Load: 20 A / 10 A
Number of pins: 5 -pin connector
Switch Function: Normally Open Contact / Normally Closed Contact / Changeover Contact
Assembly by qualified personnel required!

OE references: BOBCAT L000005177; GOLDHOFER 178156; KENWORTH 933332201; KRONE 200855360; MERCURY MARINE 8M6800222; ROSENBAUER 36070A
