HELLA Sensor, oil temperature - 12V - 1-pin connector 6PT009107-681

Sensor, oil temperature - 12V - 1-pin connector - Bolted

The proportion of electronics in vehicles has increased continuously in recent years. A development in which HELLA has long played a special role as an innovation leader in the field of automotive original equipment. The independent aftermarket also benefits in particular from this long-standing original equipment expertise - because HELLA successfully transfers its comprehensive OE know-how to this area and makes optimum use of the existing expert knowledge in this way. The temperature sensors from HELLA are versatile: Oil, coolant, intake air, outside and interior temperatures can be precisely recorded with them. The changing resistance is used by various control units for further calculations. The sensor, which is manufactured in-house, impresses with its robust design, which ensures the best measurement results under difficult conditions.

• fits e.g. Peugeot 306 Hatchback (7A, 7C, N3, N5) (please check exact vehicle application)
• Temp. Range: 25/80°C
• NTC Sensor - Thread Size: M14x1,25 - Spanner size: 19
• Colour: Blue - Corresponds to the original part in colour: BlueColour Coding: Red
• HELLA oil temperature sensors use Negative Temperature Coefficient thermistor technology to deliver accurate oil temperature readings for efficient engine management.
• Measures engine oil temperature, allowing the ECU to adjust performance until optimal operating conditions are reached.
• HELLA oil temperature sensors help ensure engine protection and performance, with real-time data also displayed on the dashboard in many vehicles.

Item Attributes:
Mounting Type: Bolted
Voltage: 12 V
Resistor: 238 Ohm / 2053 Ohm
Temp. Range: 80 °C / 25 °C
Thread Size: M14x1,25
Colour: Blue
Spanner size: 19
Sensor Type: NTC Sensor
Number of pins: 1 -pin connector
Colour Coding: Red
Corresponds to the original part in colour: Blue
SVHC: 7439-92-1; Lead
Assembly by qualified personnel required!

OE references: CITROËN 1338.09; CITROËN 96.018.426; FERRARI 9601842680; FIAT 9601842680; HYUNDAI 94650-29001; LANCIA 9601842680; PEUGEOT 1338.09; PEUGEOT 96018426
