HELLA Signal Horn - B36 - 24V - 105dB(A) - High Tone - Quantity: 1 3BA002768-201

Signal Horn - B36 - 24V - 105dB(A) - Frequency Range: 400Hz - High Tone - Electric - ECE - Housing Colour: Grey - Flat Plug-in Connector - Quantity: 1

Play it safe - with the signal horns from HELLA. Signal horns are an absolute necessary and legally required accessory - and an essential safety feature. In view of the ever-increasing traffic in cities with millions of inhabitants, horn signals are essential to avoid accidents and collisions. An acoustic signalling device is used to ensure the safety of pedestrians but also other drivers. Horns come in a wide variety of designs and signal effects, depending on the intended use and requirement profile. HELLA offers a wide range of horns, each with a different sound. Over 100 years of experience in the development of horns and fanfares and continuous innovations through research - this is what distinguishes HELLA horns. Whether car, truck, bus, emergency or motorbike, our horns are used everywhere.

• Signal horn B36 (Ø 112 mm) with ECE / ECE-R28 approval, with E-mark and moisture protection
• Sound pressure level at 2 m distance: 116 dB(A)
• Galvanised metal housing, black diaphragm, with 6.3 mm blade terminals, protected, holder on horn for M8 fixing screw, with Teflon pill for protection against moisture
• Temperature range from: -40°C - Temperature range to: +60°C - Frequency Range: 400Hz - Power consumption: 72W
• Ø: 112mm - Width: 113mm - Overall Height: 129mm - Depth: 60mm
• Registration Type: ECE - fulfils ECE standard: R28 - Prot.type (IP Code): IP5K9K/IP6K7
• with E quality seal/with moisture protection

Item Attributes:
Voltage: 24 V
Power consumption: 72 W
Sound Level: 105 dB(A)
Frequency Range: 400 Hz
Charging Rate: 3 A
Prot.type (IP Code): IP5K9K / IP6K7
fulfils ECE standard: R28
Registration Type: ECE
Housing Colour: grey
Signal: High Tone
Quantity: 1
Operating Mode: Electric
Overall Height: 129 mm
Width: 113 mm
Ø: 112 mm
Depth: 60 mm
Temperature range from: -40 °C
Temperature range to: +60 °C
Mounting Type: Flat Plug-in Connector
Supplementary Article/Supplementary Info 2: with E quality seal / with moisture protection
Assembly by qualified personnel required!

OE references: HITACHI E15005740; KOMATSU 421 06H9 030; KOMATSU 421 06H9 031; KOMATSU 421-06-H9030; KOMATSU 42106H9031; NISSAN 25610-9X60A; ROSENBAUER 791368; STILL 161421; ZOOMLION 1020403010
