HELLA Signal Horn - B36 - 48V - 105dB(A) - Low Tone - Quantity: 1 3BA002768-771

Signal Horn - B36 - 48V - 105dB(A) - Frequency Range: 335Hz - Low Tone - Electric - ECE - Housing Colour: Grey - Flat Plug-in Connector - Quantity: 1

Play it safe - with the signal horns from HELLA. Signal horns are an absolute necessary and legally required accessory - and an essential safety feature. In view of the ever-increasing traffic in cities with millions of inhabitants, horn signals are essential to avoid accidents and collisions. An acoustic signalling device is used to ensure the safety of pedestrians but also other drivers. Horns come in a wide variety of designs and signal effects, depending on the intended use and requirement profile. HELLA offers a wide range of horns, each with a different sound. Over 100 years of experience in the development of horns and fanfares and continuous innovations through research - this is what distinguishes HELLA horns. Whether car, truck, bus, emergency or motorbike, our horns are used everywhere.

• Signal horn B36 (Ø 112 mm) for electric vehicles or call and alarm systems - with ECE approval, moisture protection and capacitor
• Sound pressure level at 2 m distance: 116 dB(A)
• Galvanised metal housing, with 6.3 mm blade terminals, protected, holder on horn for M10 fixing screw, with Teflon pill for protection against moisture and interference suppression capacitor
• Temperature range from: -40°C - Temperature range to: +60°C - Frequency Range: 335Hz - Power consumption: 62W
• Ø: 112mm - Width: 113mm - Overall Height: 129mm - Depth: 60mm
• Registration Type: ECE - fulfils ECE standard: R28 - Prot.type (IP Code): IP6K9K/IP6K7
• with condenser/with moisture protection

Item Attributes:
Voltage: 48 V
Power consumption: 62 W
Sound Level: 105 dB(A)
Frequency Range: 335 Hz
Charging Rate: 1.3 A
Prot.type (IP Code): IP6K9K / IP6K7
fulfils ECE standard: R28
Registration Type: ECE
Housing Colour: grey
Signal: Low Tone
Quantity: 1
Operating Mode: Electric
Overall Height: 129 mm
Width: 113 mm
Depth: 60 mm
Ø: 112 mm
Interference Suppression
Temperature range from: -40 °C
Temperature range to: +60 °C
Mounting Type: Flat Plug-in Connector
Supplementary Article/Supplementary Info 2: with condenser / with moisture protection
Assembly by qualified personnel required!

OE references: DEUTZ-FAHR 000 9731513; HAKO 90-19491-1; JUNGHEINRICH 018843; JUNGHEINRICH 08300030; JUNGHEINRICH 28306500; LINDE 000 973 15 13; LINDE 000 973 15 36; STEINBOCK 018 843; STILL 020542; STILL 357377; STILL 428286; STILL 500164; STILL 8020542
