HELLA Signal Horn - HELLA HEAVY DUTY HORN B133 - 24V - 110dB(A) - High Tone - Quantity 3AF003399-071

Signal Horn - HELLA HEAVY DUTY HORN B133 - 24V - 110dB(A) - Frequency Range: 500Hz - High Tone - Electric - ECE - Housing Colour: Black - Flat Plug-in Connector - Quantity: 1

Over 120 years of experience in the development of horns & fanfares and continuous innovations through research - this is what distinguishes HELLA horns. Whether car, truck, bus, emergency or motorbike, our horns are used everywhere.

• Black housing, black protection grid and black holder, made of galvanised metal
• Sound pressure level at 2m distance: 118 dB(A); power consumption: 24V, 84W
• Holder for fixing screw M8
• Operating temperature: -40 °C to 90 °C (-40 °F to 194 °F)
• With 6.3 mm tab terminals, open; approval: ECE
• Temperature range from: -40°C - Temperature range to: 75°C - Frequency Range: 500Hz - Power consumption: 84W
• Ø: 123mm - Width: 125mm - Overall Height: 135mm - Depth: 85mm

Item Attributes:
Voltage: 24 V
Power consumption: 84 W
Sound Level: 110 dB(A)
Frequency Range: 500 Hz
Charging Rate: 3.5 A
Prot.type (IP Code): IPX7 / IPX9K
fulfils ECE standard: R28
Registration Type: ECE
Housing Colour: black
Signal: High Tone
Quantity: 1
Operating Mode: Electric
Overall Height: 135 mm
Width: 125 mm
Depth: 85 mm
Ø: 123 mm
Interference Suppression
Special Purpose Vehicle: for special-purpose vehicles
Temperature range from: -40 °C
Temperature range to: 75 °C
Mounting Type: Flat Plug-in Connector
Supplementary Article/Supplementary Info 2: with rubber grommet / with moisture protection / without E quality seal / with condenser
Assembly by qualified personnel required!

OE references: BUCHER 7-661-0811; CASE IH 2929215; DEMAG 00093012; DOOSAN 2516-9015; KAMAG 80069119; KÄSSBOHRER 7 711 119 000; KÄSSBOHRER 7.711.119.000.0; KÖGEL 69119; KÖGEL 80069119; LIEBHERR 1 067 552 6; LIEBHERR 10475526; LIEBHERR 6 205 045; MAFI 000,580,2436; MAN 81.25301-6044; MERCEDES-BENZ 002 542 48 20; MERCEDES-BENZ 003 542 48 20; MERCEDES-BENZ A 002 542 48 20; MERCEDES-BENZ A 003 542 48 20; O&K 2929215; PUTZMEISTER 018974005; ROSENBAUER 41139A; SANY 60162458; TEREX 00093012; TEREX 94700093012; VOLVO 14532551
