HELLA Signal Horn - HELLA HEAVY DUTY HORN B36 - 12V - 116dB(A) - High Tone - Quantity: 3BA002768-082

Signal Horn - HELLA HEAVY DUTY HORN B36 - 12V - 116dB(A) - Frequency Range: 335Hz - High Tone - Electric - ECE - Housing Colour: grey/black - Flat Plug-in Connector - Quantity: 1

Over 120 years of experience in the development of horns & fanfares and continuous innovations through research - this is what distinguishes HELLA horns. Whether car, truck, bus, emergency or motorbike, our horns are used everywhere.

• Housing and holder in black galvanised metal, black membrane
• Sound pressure level at 2 m distance: 116 dB(A); power consumption: 72 W
• Holder for fixing screw M8
• Operating temperature: -40 °C to 90 °C (-40 °F to 194 °F)
• Approval: ECE
• Temperature range from: -40°C - Temperature range to: +60°C - Frequency Range: 335Hz - Power consumption: 72W
• Ø: 112mm - Overall Height: 129mm - Depth: 53mm

Item Attributes:
Voltage: 12 V
Power consumption: 72 W
Sound Level: 116 dB(A)
Frequency Range: 335 Hz
Charging Rate: 6 A
Prot.type (IP Code): IP54
fulfils ECE standard: R28
Registration Type: ECE
Housing Colour: grey/black
Quantity: 1
Signal: High Tone
Operating Mode: Electric
Overall Height: 129 mm
Ø: 112 mm
Depth: 53 mm
Temperature range from: -40 °C
Temperature range to: +60 °C
Mounting Type: Flat Plug-in Connector
Supplementary Article/Supplementary Info 2: with E quality seal
Assembly by qualified personnel required!

OE references: AEBI 18-6250401; AHLMANN 0229044/0229026; ATLAS COPCO 0448613; BMW 1 357 089; BMW 1 367 309; BMW 61 33 1 357 089; BUCHER 30/14; BUCHER 7-661-0510; DAF 545963; DELVANO 8040149; DEMAG 50131298; GOLDHOFER 19297; JOHN DEERE WZ32601195F; KÖGEL 307368; KRAMER 000 332 18 05; LEYLAND DAF EXAELD622; LINDE 2024213001; MACK 4381 66010; MAFI 000,580,2404; MAN 81.25301-6048; MAN 81.25301-6074; O&K 8475404; PUTZMEISTER H3177110317; SCHMITZ CARGOBULL 980480; TEREX 0448613; TEREX 50131298; VALMET 389680; VAN HOOL 660760205; VDL 660760205; VÖGELE 3515160002; VOLVO 20007049671; VOLVO 7049671; WEIRO 15276
