HELLA Signal Horn - HELLA HEAVY DUTY HORN B36 - 24V - 105dB(A) - High Tone - Quantity: 3BA002768-431

Signal Horn - HELLA HEAVY DUTY HORN B36 - 24V - 105dB(A) - Frequency Range: 400Hz - High Tone - Electric - ECE - Housing Colour: grey/black - Flat Plug-in Connector - Quantity: 1

Over 120 years of experience in the development of horns & fanfares and continuous innovations through research - this is what distinguishes HELLA horns. Whether car, truck, bus, emergency or motorbike, our horns are used everywhere.

• Full harmonious sound over long distances in road traffic
• Optimum sound when a set of tweeter and bass horn is installed.
• Membrane to protect against moisture penetration
• The horn is switched by the "horn" on the steering wheel (control signal).
• Teflon seal to protect against moisture (optional).
• Temperature range from: -40°C - Temperature range to: +60°C - Frequency Range: 400Hz - Power consumption: 72W
• Ø: 112mm - Overall Height: 129mm - Depth: 53mm

Item Attributes:
Voltage: 24 V
Power consumption: 72 W
Sound Level: 105 dB(A)
Frequency Range: 400 Hz
Charging Rate: 3 A
Prot.type (IP Code): IP5K9K
fulfils ECE standard: R28
Registration Type: ECE
Housing Colour: grey/black
Quantity: 1
Signal: High Tone
Operating Mode: Electric
Overall Height: 129 mm
Ø: 112 mm
Depth: 53 mm
Temperature range from: -40 °C
Temperature range to: +60 °C
Mounting Type: Flat Plug-in Connector
Supplementary Article/Supplementary Info 2: with E quality seal
Assembly by qualified personnel required!

OE references: DEMAG 27067140; DEMAG 27067140X; FAUN 94727067140; FIAT 42046130; IVECO 42046130; IVECO 42046130EZ502382; KOMATSU 20G-06-K1730; LEYLAND DAF VCS190; LIEBHERR 6 140 032; LINDE 001 973 15 02; LINDE 2025488002; MAN 36.25301-6001; MAN 81253016051; ROSENBAUER 533702; SISU 187-602-0081; SISU 187-602-0083; TAM 5597809; TEREX 27067140; TIMBERJACK F05312; VDL 189579; VDL 20189579; VERSATILE 86094455; VISEON 44.15710-0000; VOLVO 11306643; VOLVO 20003402621; VOLVO 3402621; VOLVO VCS190; VOLVO ZM3402621; ZOOMLION 1020403011
