Description
Socket - 12V - 7-pin connector - Screw Connection - Plug: Round Plug - Black - DIN/ISO: 7638-2 - Quantity: 1
The plug-in systems according to ISO 7638-1 / ISO 7638-2 are used in almost all commercial vehicles with ABS/EBS systems. The connectors are suitable for ADR /GGVS applications.
- Original equipment quality
- Easy assembly
- ABS/EBS plug-in system according to ISO 76 38-2
- Temperature range from: -40°C - Temperature range to: +85°C - from: 1.5mm² - to: 6.0mm²
- Prot.type (IP Code): IP54
- with protective cap/bellow - for vehicles with ABS
Item Attributes:
Number of pins: 7 -pin connector
Voltage: 12 V
Current Strength from: 15 A
Current Strength to: 30 A
Cable Ø from: 9 mm
Cable Ø to: 16 mm
from: 1.5 mm²
to: 6.0 mm²
Temperature range from: -40 °C
Temperature range to: +85 °C
Prot.type (IP Code): IP54
Mounting Type: Screw Connection
DIN/ISO: 7638-2
Colour: black
Braking/Driving Dynamics: for vehicles with ABS
Supplementary Article/Supplementary Info 2: with protective cap/bellow
Plug: Round Plug
Quantity: 1
Assembly by qualified personnel required!
OE references: LIEBHERR 1 184 1254; LINDNER 3010184; MAFI 000,579,2964; SCANIA SP1050977
