HELLA Socket - 2-pin connector - Flat Plug-in Connector - Plug: Blade Terminal - Quant 8JB002286-021

Socket - 2-pin connector - Flat Plug-in Connector - Plug: Blade Terminal - Black - DIN/ISO: 4165 - Quantity: 10

The tried-and-tested plug-in system according to ISO 4165 allows an additional connection option for supplying a variety of small consumers, such as lights, fans, coolers, telephones, laptops, portable refrigerators, coffee machines etc. Depending on the version, the plug-in systems can be installed both inside and outside the vehicle. The universal plugs allow the use of both systems with one and the same plug due to the red front adapter. Here, too, the HELLA range offers the right design for almost every application thanks to its wide variety.

• Easy assembly
• Various connection options
• Sockets with and without cover
• 2-pole plug-in system according to ISO 4165
• without lid

Item Attributes:
Number of pins: 2 -pin connector
Voltage from: 6 V
Voltage to: 24 V
DIN/ISO: 4165
Colour: black
Rated Current: 8 A
Mounting Type: Flat Plug-in Connector
Supplementary Article/Supplementary Info 2: without lid
Socket Width: 6.3 mm
Plug: Blade Terminal
Quantity: 10
Assembly by qualified personnel required!

OE references: DAF 08078912; HYMER 9775590; HYMER 9975590; JOHN DEERE 50 65 02; LIEBHERR 6 050 093; LIEBHERR 6 052 093; LIEBHERR 6 052 116 01; ROSENBAUER 046706; VW 271 925 071 B
