Description
Trumpet Horn - HELLA STYLE HORN TE24 - 12V - 110dB(A) - Frequency Range: 500Hz - High Tone - Electric - ECE - Housing Colour: Red/Black - Flat Plug-in Connector - Quantity: 1
Over 120 years of experience in the development of horns & fanfares and continuous innovations through research - this is what distinguishes HELLA horns. Whether car, truck, bus, emergency or motorbike, our horns are used everywhere.
- 110 dB(A) Sound pressure level at 2 m distance
- 72W Power consumption per fanfare
- Full, harmonious sound and wide sound dispersion
- Sporty design
- Style Range - a harmonious combination of style and content
- Temperature range from: -40°C - Temperature range to: +80°C - Frequency Range: 500Hz - Power consumption: 72W
- Width: 109mm - Overall Height: 89mm - Depth: 80mm
Item Attributes:
Voltage: 12 V
Power consumption: 72 W
Sound Level: 110 dB(A)
Frequency Range: 500 Hz
Charging Rate: 6 A
Prot.type (IP Code): IP65
fulfils ECE standard: R28
Registration Type: ECE
Signal: High Tone
Housing Colour: red/black
Quantity: 1
Operating Mode: Electric
Overall Height: 89 mm
Width: 109 mm
Depth: 80 mm
Temperature range from: -40 °C
Temperature range to: +80 °C
Mounting Type: Flat Plug-in Connector
Supplementary Article/Supplementary Info 2: with E quality seal
Assembly by qualified personnel required!
OE references: AGCO 83103900; AGCO V83103900; ARTEGA 80-933-002-00; ATLAS COPCO 800001103; BMW 1 374 440; CASE IH 2152737; FENDT V 831 039 00; JUNGHEINRICH 51097258; MACK 4381 85102; MACK 4381 85104; MCLAREN 16MA209CP; MCLAREN 16MB361CP
