HELLA Wheel Sensor, tyre-pressure monitoring system 6PP358139-531

Wheel Sensor, tyre-pressure monitoring system

The proportion of electronics in vehicles has increased continuously in recent years. A development in which HELLA has long played a special role as an innovation leader in the field of automotive original equipment. The independent aftermarket also benefits in particular from this long-standing original equipment expertise - because HELLA successfully transfers its comprehensive OE know-how to this area and makes optimum use of the existing expert knowledge in this way. Tyre pressure is an essential automotive safety factor. The most frequent tyre damage is due to a gradual loss of pressure, which is often noticed too late by the drivers of the vehicle. Too low tyre pressure also leads to increased fuel consumption and poor handling. This is also associated with an increase in tyre temperature and greater wear. As a result of insufficient tyre pressure, the tyre can suddenly burst. This poses an enormous safety risk for all occupants. Therefore, tyre pressure monitoring systems (TPMS) have been mandatory for all new vehicles in the EU since November 2014. HELLA offers a reliable and high-quality safety product with the battery-powered tyre pressure monitoring sensors. They are mounted directly in the respective wheel of the vehicle and measure the temperature as well as the pressure of the tyre. The measured value of the tyre pressure is transmitted by radio to the tyre pressure control unit. This emits an optical/acoustic warning message via the display unit in the event of a registered pressure loss.

• Tightening Torque: 4.5Nm
• HELLA TPMS sensors measure and compare internal tyre pressure with ambient pressure, sending real-time data to the ECU for accurate monitoring.
• Instantly alerts the driver via dashboard display if one or more tyres lose pressure, enhancing road safety and preventing accidents.
• Can improve fuel efficiency and tyre lifespan by helping maintain correct tyre pressure—saving money and reducing emissions.
• Built to last—HELLA tyre pressure sensors are resistant to vibration, impact, heat, and dirt, ensuring reliable performance in all driving conditions.
• Pre-programmed for easy installation and reusable throughout the tyre’s life cycle.

Item Attributes:
Frequency Range: 433 MHz
Tightening Torque: 4.5 Nm
Valve Stem Material: Metal
Colour: Silver
Assembly by qualified personnel required!

OE references: MERCEDES-BENZ 000 905 84 13; MERCEDES-BENZ 000 905 87 06; MERCEDES-BENZ 0009058413; MERCEDES-BENZ 0009058706; MERCEDES-BENZ 0009058706/A000; MERCEDES-BENZ A 000 905 84 13; MERCEDES-BENZ A 000 905 87 06; MERCEDES-BENZ A0009058706/A0009058413
