Relay, main current - 12V - 5-pin connector - W2 - B1

Relay, main current - 12V - 5-pin connector - Wiring Diagramme: W2 - Plug: B1 - Normally Closed Contact/Normally Open Contact/Changeover Contact - Colour: Black - with holder/Waterproof

HELLA's quality relays are versatile and always reliable - that's what our many years of original equipment experience and our high level of manufacturing expertise stand for. We produce more than 100 million relays per year in our own production. Renowned car manufacturers have been relying on HELLA's proven quality for decades. The areas of application are varied and include engine control units, headlight cleaning systems, starters, fuel pumps, fan motors, horns and fanfares. HELLA is also certified in various relevant areas, such as DIN EN ISO 9001:2008, ISO / TS 6949:2009, ISO 14001. HELLA relays also comply with the standards of ROHS (2002 / 95 / EC) and REACh. They are available in 12 V and 24 V.

Mini relay - change-over relay 12 V, 5-pole, with holder and parallel resistor to coil
Rated switching current: min. 6 A, max. 30 A (at 80 °C ambient temperature)
Number of gear changes: min. 60,000
Temp. Range: 80°C
Ohmic Load: 20/30A - Inductive Load: 20/6A - Capacitive Load: 10/20A - Capacity at 12V: 20/30A
Prot.type (IP Code): 54/6K7 / 6K9K
with resistor

Item Attributes:
Supplementary Article/Info 2: with resistor
Supplementary Article/Supplementary Info: Waterproof / with holder
Prot.type (IP Code): 54 / 6K7 / 6K9K
Voltage: 12 V
Capacity at 12V: 20/30A
Colour: Black
Inductive Load: 6 A / 20 A
Capacitive Load: 10 A / 20 A
Ohmic Load: 30 A / 20 A
Number of pins: 5 -pin connector
Wiring Diagramme: W2
Combi Switch Function: Changeover Contact / Normally Closed Contact / Normally Open Contact
Plug: B1
SVHC: 1303-86-2; Diboron trioxide / 7439-92-1; Lead
Temp. Range: 80 °C
Assembly by qualified personnel required!
