HC Cargo Aircon Compressor 240891

Voltage: 12
Family type: 10S17C
Mount. holes/front 2: 8.50
Dist. between holes 1: 70.00
Dist. between holes 2: 70.00
Dist. between holes 3: 72.00
Dist. between mount. bracket/hole: 141.00
Dist. between mount. bracket/hole 2: 141.00
Dist. between mount. bracket/hole 3: 138.00
Position: 55
Position 2: 52
Length mm: 233.00
Rotation: CW
Inlet: 18.30
Outlet: 15.50
Pulley Dist. B1: 45.00
Pulley Dist. B2: 27.00
Pulley Grooves: 6
Pulley type: SP
Pulley OD mm: 119.00
Oil type: PAG 46
Oil capacity: 150 ml.
Refrigerant: R134a
O-ring: w/o
Remarks: IMPORTANT! Oil Filling. 1. Drain the oil from the compressor and measure the amount of oil. 2. Fill with the additional oil quantity and oil type as required from the vehicle manufacturer. Please be careful not to combine the different kinds of oil types.

Replaces OEM reference(s):
Chrysler 55116839AA, Chrysler K55116839AA, Denso 2473001670, Denso 4471804620, Denso 447220-4840, Jeep, see Chrysler K55116839AA

Replaces aftermarket reference(s):
Denso DCP06021, Elstock 51-0734, FrigAir 92030191, Hella 8FK351105-121, Nissens 89315
