HC Cargo Aircon Compressor 240971
Key part information
The most useful product information is shown here at a glance, including identification, application and reference numbers.
Item specifics
Description
Voltage: 12
Family type: CVC5
Mount. holes/front 2: 8.50
Dist. between holes 1: 80.00
Dist. between holes 2: 80.00
Dist. between mount. bracket/hole: 135.00
Dist. between mount. bracket/hole 2: 135.00
Position: 58
Position 2: 55
Length mm: 224.00
Rotation: CW
Inlet: 21.00
Outlet: 15.50
Pulley Dist. B1: 63.50
Pulley Dist. B2: 45.50
Pulley Grooves: 6
Pulley type: SP
Pulley OD mm: 115.00
Oil type: PAG 46
Oil capacity: 150 ml.
Refrigerant: R134a
Remarks: IMPORTANT! Oil Filling. 1. Drain the oil from the compressor and measure the amount of oil. 2. Fill with the additional oil quantity and oil type as required from the vehicle manufacturer. Please be careful not to combine the different kinds of oil types.
Replaces OEM reference(s):
Nissan 92600-1DB0A, Nissan 92600-1DB3A, Nissan 92600-JD200, Valeo 813346
Replaces aftermarket reference(s):
Delphi TSP0155927, Denso DCP46014, Elstock 51-0721, FrigAir 92010955, Hella 8FK351340-211, Hella 8FK351340711, NRF 32482, NRF 32482G
