HC Cargo Aircon Compressor 241028
Key part information
The most useful product information is shown here at a glance, including identification, application and reference numbers.
Item specifics
Description
Voltage: 12
Family type: DCS17EC
Mount. holes/front 2: 8.50
Dist. between holes 1: 80.00
Dist. between holes 2: 80.00
Dist. between mount. bracket/hole 2: 101.50
Position: 55
Position 2: 52
Length mm: 230.00
Inlet: 21.30
Outlet: 15.50
Pulley Dist. B1: 87.00
Pulley Dist. B2: 69.00
Pulley Grooves: 6
Pulley type: SP
Pulley OD mm: 120.00
Oil type: PAG 46
Oil capacity: 180 ml.
Refrigerant: R134a
O-ring: w/o
Remarks: IMPORTANT! Oil Filling. 1. Drain the oil from the compressor and measure the amount of oil. 2. Fill with the additional oil quantity and oil type as required from the vehicle manufacturer. Please be careful not to combine the different kinds of oil types.
Replaces OEM reference(s):
Renault 7711497037, Renault 8200720417, Renault 8200898810
Replaces aftermarket reference(s):
Ava (Quality Cooling) RTK393, Delphi TSP0155878, Elstock 51-0591, FrigAir 92052071, Hella 8FK351322-151, Nissens 89386, NRF 32670G, Teamec 8629544, Valeo 813147
