HC Cargo Aircon Compressor 241061
Key part information
The most useful product information is shown here at a glance, including identification, application and reference numbers.
Item specifics
Description
Voltage: 12
Family type: VS12M
Mount. holes/front 2: 8.50
Dist. between holes 1: 68.00
Dist. between holes 2: 68.00
Dist. between mount. bracket/hole: 69.00
Dist. between mount. bracket/hole 2: 103.00
Position: 46
Position 2: 50
Length mm: 227.00
Inlet: 18.90
Outlet: 12.90
Pulley Dist. B1: 94.00
Pulley Dist. B2: 76.00
Pulley Grooves: 6
Pulley type: SP
Pulley OD mm: 124.00
Oil type: PAG 46
Oil capacity: 165 ml.
Refrigerant: R134a
Source: Denso
Remarks: IMPORTANT! Oil Filling. 1. Drain the oil from the compressor and measure the amount of oil. 2. Fill with the additional oil quantity and oil type as required from the vehicle manufacturer. Please be careful not to combine the different kinds of oil types.
Replaces OEM reference(s):
Kia 977012K000, Kia 97701-2K001
Replaces aftermarket reference(s):
Ava (Quality Cooling) KAK159, FrigAir 92081124, Hella 351001351, Hella 8FK351001-351, Teamec 8623352
