TOPDON TS005 Advanced Thermal Monocular with 35mm Adjustable Lens TS005
Key part information
The most useful product information is shown here at a glance, including identification, application and reference numbers.
Item specifics
Description
The TS005 is a high-end thermal monocular designed for long-distance observation, search and rescue, surveillance, and outdoor activities. Its 35mm lens, combined with a 384×288 IR sensor and <35 mK sensitivity, captures extremely fine thermal details, even at distances up to 1,400 yards. The 1024×768 OLED viewfinder delivers exceptional clarity, while the 650-yard laser rangefinder ensures precise targeting. Featuring 8× zoom, 5 imaging palettes, 64GB internal storage, silent operation, and removable batteries, the TS005 is a versatile and durable tool ideal for professionals.
- Adjustable 35mm lens with long‑range detection up to 1400 yards
- Integrated laser rangefinder up to 650 yards
- 384×288 IR resolution with NETD < 35mK for high‑clarity thermal imaging
- 50Hz frame rate for smooth tracking of moving targets
- 8× digital zoom for detailed long‑distance observation
- 1024×768 OLED display with 12µm sensor
- Supports 5 palettes: Red‑Hot, Iron, Rainbow, White‑Hot, Black‑Hot
- Two replaceable 18650 batteries with safe polarity‑free insertion
- Up to 6 hours runtime, USB‑C rechargeable
- Silent operation and no indicator lights for stealth use
- Rugged aluminium housing, drop‑resistant and corrosion‑resistant
- Tripod mount or one‑hand use
- 64GB internal storage for millions of images or hours of video
- Built‑in compass for navigation
- Suitable for wildlife, search & rescue, law enforcement, outdoor security
